Description

Vørulýsing

• Trigger accuracy: ±3 % tolerance from the set scale value
• High level of repetition accuracy and precision for at least 5000 load cycles
• For controlled anti-clockwise and clockwise tightening
• Knurled turning knob on the reversible square drive for manual adjustment
• The actuation direction is changed by pushing the square drive through
• Dual scale in N•m and lbf•ft graduations for precise adjustment
• Includes finely divisible N•m micrometre scale for fine and precise adjustment
• Large viewing window with magnifying function for optimum readability
• Clearly audible and perceptible torque trigger thanks to quick-release function
• Robust 30-tooth ratchet mechanism
• Quick and reliable torque adjustment by turning the handle
• Secure locking feature on the handle
• Ergonomic and comfortable two-component handle with soft-grip zone
• Square drive in accordance with DIN 3120 – ISO 1174 with ball lock
• Individual serial number for clear product identification
• Includes certificate in accordance with DIN EN ISO 6789 – based on national standards

Góð ráð

• Release the load after every application by twisting the torque mechanism to the 0 position.
• The torque wrench must be inspected (calibrated) at specified intervals, as for every measuring tool.
• Calibration certificates are valid for a maximum of 12 months from the time of commissioning. If the tool is used frequently,
• this period should be reduced. A period should be specified after an assessment in accordance with DIN EN ISO 6789, section 5.3.2, after 5000 actuations.
